| din | 3a | iso | sms | h | a | b | c |
dn40 g l rd65x1/6 22.0 | 1 1/2" g l 50.5x1/8tacme 18.3 | φ38 g l 50.6x1/8 tacme 21.5 | 38 g l rd60x16 20.0 | 552.0 | 68.0 | 62.0 | 93.0 |
dn50 g l rd78x1/6 22.0 | 2" g l 64.17x1/8tacme 19.1 | φ51 g l 64.2x1/8 tacme 21.5 | 51 g l rd70x1/6 20.0 | 604.0 | 68.0 | 62.0 | 93.0 |
2 1/2" g l 77.67x1/8 tacme 22.2 | φ63 g l 77.7x1/8 tacme 21.5 | 63 g rd85x1/6 | 628.0 | 84.5 | 81.3 | 95.0 | |
dn65 g l rd95x1/6 24.0 | 3" g l 77.67x1/8tacme 22.2 | φ76 g l 91.2x1/8 tacme 21.5 | 76 g rd98x1/6 | 686.0 | 93.5 | 93.5 | 116.0 |
dn80 g l rd110x1/4 28.0 | 707.0 | 118.5 | 115.0 | 138.0 | |||
dn100 g l rd130x1/4 28.0 | 4" g l 119.25x1/9tacme 26.2 | φ120 g l 118.4x1/8 tacme 21.5 | 102 g l rd125x1/4 26.0 | 753.0 | 118.5 | 115.0 | 138.0 |
