| dn | size | a | b | c | l | d |
| dn15 | 3/4" | 108 | 18 | 15 | 90.5/99.5 | 65 |
| dn20 | 118 | 22 | 19 | 111.5/122 | 89 | |
| dn25 | 1" | 127 | 28 | 25 | 111.5/122 | 89 |
| dn32 | 1 1/4" | 146 | 34 | 31 | 131/148.5 | 109 |
| dn40 | 1 1/2" | 160 | 40 | 37 | 131/148.5 | 109 |
| dn50 | 2" | 190 | 52 | 49 | 162/184.5 | 139 |
| dn65 | 2 1/2" | 216 | 70 | 67 | 199/228 | 200 |
| 3a | size | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" |
| b | 19.05 | 25.4 | 31.8 | 38.1 | 50.8 | |
| c | 15.75 | 22.1 | 28.5 | 34.8 | 47.5 |
| sms/iso | size | 19 | 25 | 32 | 38 | 51 |
| b | 19.05 | 25.4 | 31.8 | 38.1 | 50.8 | |
